B-Series Murphygage®

The B-Series Murphygage® instrument is a high-quality, diaphragm-actuated indicating gage.

Built by Enovation Controls with the same heavy-duty design as the standard 20 series and 25 series Swichgage® instrument, the B-gage is more compact and is the optimum instrument for gage-only applications.

The B-Series can be utilized in industrial engines and equipment for oil and gas, marine, irrigation, construction and trucking industries as well as monitoring engine coolant, crankcase oil and transmission oil.

20BTG-250
Base Models Specifications Downloads How To Order
X

Each Murphygage instrument has a high impact polycarbonate lens, sturdy steel case and a polished, low-profile stainless steel bezel. Accuracy and protection from moderate over-pressure/overtemperature are assured by a unique, unitized diaphragm chamber, superior quality materials and the design of the gage movement.

Pressure Murphygage instrument
Pressure changes at the diaphragm convert to accurate mechanical movements that are indicated on an easy-toread analog dial. A pulsation dampener in the pressure port helps eliminate pointer flutter. It can be removed for cleaning to maintain the gage’s response and accuracy.

Vacuum Murphygage instrument
Available in 0 to 20 or 0 to 30 in. Hg. (0 to -68 or 0 to -102 kPa) vacuum.

Temperature Murphygage instrument
As temperature rises, the fluid in the sensing bulb vaporizes to apply pressure on the diaphragm. The movement translates this vapor pressure to a calibrated reading of temperature on the dial. The standard capillary is copper with a PVC armor. Optional armor covering is galvanized steel or 316 stainless steel (specify). Optional bulb types, adaptor nuts and thermowells are available.

  • Dial: White on black; U.S.A. standard scale is dual scale; others available.
  • Gage Accuracy: See Technical Bulletin
  • Temperature Range:
    • Pressure/Vacuum:
      • Process: -40° to 250° F (-40° to 121° C)
      • Ambient: -40° to 150° F (-40° to 66° C)
    • Temperature: See Technical Bulletin
  • Maximum Panel Thickness: 1/4 in. (6 mm)
  • Port: Brass
  • Case: Plated steel; mounting clamp included (except for direct mount models)
  • Bezel: Polished stainless steel, standard; optional bezels are available.
  • Pointer: White (black dial); black (white dial)
  • Lens: Polycarbonate, high-impact
  • Sensing Element: Beryllium copper diaphragm
